Air Valves

Air Valves

Home + Products + Air Valves
Air Vacuum Valves Slide-01

Engineered to Prevent Water Hammer & Surge Damage

OG corrosion-resistant Air Release/Vacuum Valves are well suited to severe service environments. We offer a wide range of materials, including Super Duplex, Titanium, Stainless Steel, Duplex, 6Mo, Hastelloy ®, Monel®, Vistar®, Inconel® and Aluminium Bronze. These materials give superior protection for seawater service and other harsh service mediums.

Utilising Norsok-approved foundries, we can offer our global customers lower-quantity fast-track MRO requirements and larger-quantity multi-valve project requirements. Extensive material testing and certification are standard for each air valve.

Air vacuum valves installed in pipeline systems are used to perform either of these three essential functions:

  1. Release accumulated air pockets from pipes during normal system operation
  2. Allow air to enter the pipeline when negative pressure occurs (vacuum protection)
  3. Release large volumes of air when filling the pipeline and allow air entry when draining

Air release valves are designed to release air pockets from pressurised pipelines. They protect against high shock pressure and water hammer in freshwater or seawater pipelines.

Types of Air Release valves:

  • Air-Release (small orifice)
  • Air/Vacuum (air vent and vacuum)
  • Combination (air release, vent, and vacuum)

Benefits

  • Pressure & Vacuum relief function
  • Surge and water hammer prevention
  • Liquid overflow protection
  • Providing high-capacity venting for pipeline protection
  • Prevents pipe damage by allowing air entry during negative pressure
  • Protects pumps from cavitation damage
  • Prevents air-related system failures
  • Prevents dangerous pressure

Contact our engineering team today to discuss your specific valve requirements and discover how our advanced Air Valves solutions can enhance your asset’s safety, reliability, and performance.

Contact Us

Material Grades

Body
Super Duplex, Titanium, Stainless Steel, Duplex, 6Mo, Hastelloy ®, Monel®, Vistar®, Inconel® and Aluminium Bronze

Range

Size

DN25 (1”) TO DN350 (14”)

Pressure Class

 JIS, ANSI, DIN, BS

Industry Sectors

  • Oil & Gas Offshore platforms
  • FPSO
  • Water Treatment Plant Piping High Points
  • Vertical Turbine Pump Discharge
  • Seawater applications
  • Petrochemical
