Flow Control for Critical Processes

Our comprehensive range of butterfly valves delivers superior performance across the most challenging industrial applications. From offshore platforms to refineries and critical pipeline infrastructure, our valves are engineered to excel in extreme conditions while maintaining the highest safety and reliability standards. Only API 609 Monogram Licensed valves are offered.
A Triple Offset Butterfly valve is an advanced butterfly valve designed for optimal sealing and performance in critical applications. These valves are commonly used in oil & gas, power generation, chemical processing, and other industrial applications where tight shutoff and high-temperature compliance are critical.
The TOG Triple Offset brand is recognised for its outstanding flow and control characteristics, tight sealing, and reliability. These precision-engineered valves excel under conditions of high pressure and temperature.

OG Models Offered

Firesafe High-Performance Triple Offset Butterfly Valve – Lugged TOG-L
Firesafe High-Performance Triple Offset Butterfly Valve – Wafer TOG-W
Firesafe High-Performance Triple Offset Butterfly Valve – Double Flanged TOG-F

Benefits

Contact our engineering team today to discuss your specific valve requirements and discover how our advanced butterfly valve solutions can enhance your asset’s safety, reliability, and performance.

Material Grades

Body
WCB, CF8, CF8M, CD3MWCuN, B148 C95800, TITANIUM, MONEL, INCONEL, HASTELLOY
Disc
WCB, CF8, CF8M, CD3MWCuN, B148 C95800, TITANIUM, MONEL, INCONEL, HASTELLOY (with Stellite or ENP)
Seat

316SS, MONEL 400, UNS S32760, TITANIUM

Shaft
SS 316, 17-4 PH, UNS S32760, K500, XM-19, INCONEL 718, C276

Range

Size
DN50 (2”) TO DN2000 (80”)
Connection Type
Double Flanged, Lugged, Wafer, Butt Weld End
Pressure Class
ANSI 150# – 1500# / DIN PN 10,16, 20, 25, 40, 64, 100
Operation
Lever, Worm gear, Pneumatic actuator, Electric actuator, Hydraulic actuator
Temperature
-50oC to 450oC

Design

ASME B16.34, API 609 Category B, API 607

Industry Sectors

  • Oil & Gas Offshore platforms
  • FPSO
  • Refineries
  • Pipeline transmission
  • Storage terminals
  • LNG facilities
  • Gas processing plants
  • Thermal power plants
  • Nuclear power stations
  • Petrochemical plants
  • Desalination plants
  • Seawater applications
  • Ethylene Plants (Molecular Sieve)
  • Ballast systems
  • Paper and pulp mills
  • Pharmaceutical manufacturing
  • Aerospace
  • Chemical manufacturing
