Side Entry Trunnion Ball Valve

Side Entry Trunnion Ball Valve

Home + Products + Side Entry Trunnion Ball Valve
Trunnion Side Entry Ball Valve Gallery

Optimal Performance for Critical Applications

OG Side Entry Trunnion Ball Valves are API Licenced and commonly used in the upstream, midstream, and downstream sectors of the Oil & Gas Industry. The OG range of trunnion-mounted ball valves are available with a 2 or 3-piece bolted body, metal or soft-seated design. Superior high-pressure performance via more reliable sealing and reduced risk of valve seat deformation. Double Block and Bleed (DBB) or Double Isolation and Bleed (DIB) functionality is available.
They incorporate sophisticated design features to provide rugged construction, reliable operation, and long service life at high and low pressures.

Benefits

  • Lower maintenance and downtime
  • Reduced risk of fugitive emissions
  • Quick opening and closing capabilities
  • Suitable for diverse applications
  • Suitable for higher-pressure applications
  • Tight sealing reduces the risk of leakage
  • Less operating torque required; therefore, smaller actuators can be utilised
  • Zero-leakage capability
  • Lower torque minimises ball, seat, and stem wear
  • Design ensures no side loads are transferred to the stem
Contact our engineering team today to discuss your specific valve requirements and discover how our advanced Side Entry Trunnion Ball Valves solutions can enhance your asset’s safety, reliability, and performance.
Contact Us

Material Grades

Body
LTCS/CS with CRA WELD overlay, Stainless steel, Duplex, HASTELLOY, Super Duplex, 6MO, Titanium, INCONEL, MONEL, Nickel alloys
Seals

Soft or Metal seated with TCC OR CCC

Design

API 6D, ASME B16.34, NACE MR 01-75, API 607, API 6FA

Range

Size
DN50 (2”) TO DN1500 (60”)
Connection Type
Flanged RF/RTJ, Clamped Hubs, Butt Weld End
Pressure Class
ANSI 150# – 2500#
Operation
Worm gear, Pneumatic actuator, Electric actuator, Hydraulic actuator
Temperature
-46oC to 250oC

Industry Sectors

  • Oil & Gas Offshore platforms
  • FPSO
  • Refineries
  • Pipeline transmission
  • Storage terminals
  • LNG facilities
  • Gas processing plants
  • Power industry
  • Petrochemical plants
  • Desalination plants
  • Seawater applications
  • Ballast systems
  • Paper and pulp mills
  • Pharmaceutical manufacturing
  • Aerospace
  • Chemical manufacturing
