Cryogenic Gate Valves

Cryogenic Gate Valves

Home + Products + Cryogenic Gate Valves
LNG Cryogenic Triple Offset Butterfly Valves Gallery

Robust Solutions for Cryogenic Applications

OG Valves technically advanced LNG Cryogenic Gate Valves deliver superior performance for Industrial Cryogenic Applications. Cryogenic applications require valves to safely operate at extremely low temperatures as low as -196ºC.

Cryogenic Valves are used extensively in the Liquefied Natural Gas (LNG) Industry. LNG is liquefied to reduce volume, enabling easier transport to global destinations.

A LNG plant consists of one or more LNG trains, each of which is an independent unit for gas liquefaction and purification. A typical train consists of a compression area, propane condenser area, and methane and ethane areas.

Benefits

  • Consistent sealing at extreme temperatures
  • Maintains tight shut-off throughout the service life
  • Bi-directional sealing capability
  • Premier Quality Castings for safety and reliability
  • Reduced risk of fugitive emissions
  • Superior operation during fluctuations in cryogenic temperatures
  • Special material handles thermal stress

Contact our engineering team today to discuss your specific valve requirements and discover how our advanced Cryogenic valve solutions can enhance your asset’s safety, reliability, and performance.

Contact Us

Material Grades

Body
CF8, CF8M, CF3, CF3M

Design

BS 6364, BS 6755, API 6FA

Range

Size

2” TO 48”

Connection Type

Flanged, Butt Weld End

Pressure Class

ANSI 150# – 1500#

Operation

Worm gear, Pneumatic, Hydraulic actuator

Temperature
-196oC

Industry Sectors

  • Liquid Oxygen Plants
  • Liquefied Natural Gas (LNG) Liquefaction Plants
  • Liquefied Natural Gas (LNG) Regasification Terminals
  • LNG carriers
  • FLNG Vessels
  • Chemical Industries
  • Petrochemical Industries
  • Aerospace Industries
  • Liquid Argon storage
  • Liquid Nitrogen storage
  • Air Separation Units
